产品特点：适合各种高腐蚀化学介质
■主要零件材料表 main part and material table
|
零件名称
Part name
|
材料Material |
|
阀体Body、
阀盖Cover
|
铸钢cast steel、不锈钢 stainless steel、内衬lining、F46 |
|
阀杆
Stem
|
优碳钢 excellent carbon steel、不锈钢 stainless steel |
|
隔膜片Diaphragm pad |
F4、F46 |
|
隔膜垫
Diaphragm sheet
|
橡胶 rubber |
|
阀杆螺母
Stem nut
|
2HMN58-2-2 |
|
手轮
Handwheel
|
HT200 |
■衬氟隔膜阀标准PTFE-Lined diaphragm valve standard
|
名称 Name |
技术规范
Technical specification
|
|
设计标准
Design criteria
|
GB12239 |
|
结构长度structure length |
GB12221 |
|
法兰标准
Flange standard
|
JB/T79-94 |
|
GB9113.1-2 |
|
|
检验试验Inspection test |
GB/T13927 |
|
驱动方式
Drive mode
|
蜗轮worm、手动manual、电动electric、气动pneumatic |
|
公称通径
Nominal diameter
|
PN1.0(MPa）主要外形尺寸和连接尺寸main form and connection size |
重量weight |
|||||||||
|
DN |
L |
D |
D1 |
D2 |
f |
b |
Z-φd |
D0 |
H1 |
H2 |
Kg |
|
15 |
125 |
95 |
65 |
42 |
3 |
14 |
4-φ14 |
100 |
90 |
98 |
4 |
|
20 |
135 |
105 |
75 |
50 |
3 |
14 |
4-φ14 |
100 |
95 |
104 |
5 |
|
25 |
145 |
115 |
85 |
60 |
3 |
16 |
4-φ14 |
120 |
125 |
139 |
6 |
|
32 |
160 |
135 |
100 |
70 |
3 |
18 |
4-φ18 |
140 |
136 |
154 |
8 |
|
40 |
1800 |
145 |
110 |
80 |
3 |
18 |
4-φ18 |
160 |
165 |
183 |
10 |
|
50 |
210 |
160 |
125 |
100 |
3 |
20 |
4-φ18 |
180 |
175 |
201 |
14 |
|
65 |
250 |
180 |
145 |
120 |
3.5 |
20 |
4-φ18 |
200 |
215 |
249 |
22 |
|
80 |
300 |
195 |
160 |
135 |
3.5 |
22 |
4-φ18 |
240 |
230 |
270 |
29 |
|
100 |
350 |
215 |
180 |
150 |
4 |
24 |
8-φ18 |
280 |
282 |
334 |
45 |
|
125 |
400 |
245 |
210 |
180 |
4 |
26 |
8-φ18 |
320 |
340 |
408 |
63 |
|
150 |
460 |
280 |
240 |
210 |
5 |
28 |
8-φ23 |
360 |
382 |
462 |
98 |
|
200 |
570 |
335 |
295 |
260 |
5 |
32 |
8-φ23 |
400 |
509 |
629 |
182 |
|
250 |
680 |
390 |
350 |
319 |
5 |
36 |
12-φ23 |
450 |
610 |
746 |
245 |
|
300 |
790 | 440 | 400 | 368 | 5 | 40 | 12-φ23 | 500 | 700 | 830 | 320 |
